Ka-Band 250 watt MOAB

The 250W MOAB Block Upconverter is the industry’s most compact & lightweight Wideband Ka-Band 250W solid state power amplifier. Mission Microwave’s proprietary power combining technology and thorough system optimization have produced a rugged 35 lb amplifier that mounts directly on an antenna boom, eliminating excess losses to the feed.

The revolutionary design features a compact form factor which provides improved cooling over more conventional package designs. Improved cooling equates to higher reliability, even in the most demanding of applications and extreme environments (-40°C to +60°C). The BUC’s stellar performance offers the highest useable output power for the lowest power consumption of any amplifier in its class.

  • Model: MOAB-KA_-250
  • Transmit Band: Ka
  • Transmit Frequency: 29-30 GHz / 30-31 GHz
  • Rated Power: 250 watt
  • Linear Power (single carrier spectral regrowth): 52 dBm / 160 watt
  • Linear Power (two tone intermodulation): 51 dBm / 125 watt
  • M&C: Ethernet via Mission GUI or SNMP V3, Serial
  • Status: Production
  • Configuration Options: M&C Interface
Additional information
Weight 35 lbs
Dimensions 17 × 10.3 × 7.5 in
Compare to other amplifiers in this class.
